LED Driver

Highlights

  • Universal AC input 90VAC ~ 300VAC
  • Protections: Short Circuit / Over current / Over voltage / Over Temperature
  • Cooling by free air convection.
  • Class II Power Unit, no FG
  • Built in active PFC function
  • Small and Compact size
  • 100% Full Load Burn-in Test.
  • ATD < 10%
  • High reliability, Low Cost

    • Specification:

    Model NPS-18 NPS-30 NPS-45 NPS-60 NPS-100 NPS-150 NPS-200
    Output Wattage 18 Watts 30 Watts 45 Watts 60 Watts 100 Watts 150 Watts 200 Watts
    Dimension (L x W x H)(mm) 88 x 38 x 22 110 x 42 x 26 132 x 45 x 26 181.5 x 61 x 46 181.5 x 71 x 46 224 x 76 x 46 224 x 76 x 46
    NPS-18
    More details
    NPS-30
    More details
    NPS-45
    More details
    NPS-60
    More details
    NPS-100
    More details
    NPS-150
    More details
    NPS-200
    More details
